TUBE AND PROFILE BENDING

---

• 100% electric drive of all 11 axles.
• Bending head with 360 ° radial axis and horizontal and vertical linear axis.
• Bending clockwise and counter clockwise in automatic cycle.
• Bending of multiple fixed and variable radii in the same cycle.
• Quick tool change, without having to readjust.
• High working speed and low power consumption.
• Axis movements controlled by servo motors with absolute encoder feedback.
• Simplified synchronisation and optimisation of bending cycles.
• Compact and ergonomic design for optimal operating comfort and
  maintenance.
• Sensors that compensate for material bending back and provide greater precision and less waste during the bending cycle.
• Powerful and intuitive VLB 3D software with anti-collision simulation.
• Easily program or import files from the cloud or from the network.

The cycle speed and low energy consumption make these machines ideal for production with a high volume and high consistency. Because the level of automation is so advanced, they are easy to integrate into automatic production lines or tot combine with automatic loading and unloading elements.

INDUSTRY 4.0 machines, thanks to the advanced VLB 3D software.

 Tube Bending Machine bends tubes up to 76 mm diameter with high quality and accuracy as servo motor contolled. This machine, that enable to work with 3 dies, provides convenience, prevents waste of time and increases efficiency, carrying out bending process consecutively and automatically with its advanced CNC feature.

· Bending, moving ahead, postponing and turning axies with servo control

· Controlling ability of servo axis speeds on control panel

· Hydraulic assistant axies

· Footpedal control

· Step by step and fully automatic working capability

· Capability to work with three dies

· Dies can be supplied for any demanded size

· Operational ability with/without mandrel

· Capability of bending steel, stainless steel, aluminum and similar bendable tubes in simple or compex shapes

· Possibility of bending longer tubes than the machine length (for certain diameters)

· Unlimited angle obtaining possibility with rolling system

· Spiral bending (only on certain diameters)

· Hydraulic oil cooler

· Auto-lubrication for mandrel

· Practical interface program prepared in Akyapak

· Program making possibility in YBC mode

· Tube length can be calculated in the part program

· Motion controller system

· 3D preview of writen program

· Motors in variable voltage and frequency

· 15” color touchscreen PC

· Starting up serial production after short period training

· Suitable for CE,ISO 9001-2015, TSEK and TURQUM certificates

Profile Bending Machine offers fast and reliable operation with a solid steel structure and motor system. They are user-friendly with strong plate rolls and eco-friendly with low energy consumption. While performing a precise bending with Durma PBM Profile Bending Machine's large shaft diameters and strong bearings, you can also minimize the margin of error. Plate rolls made of hardened and special steel and mechanical side supports ensure long-lasting use. Plate rolls and lower shafts with motor and transmission support, cast iron frame, control panel moving separately from the machine and brake motor are the standard equipment. Additionally; rod bending apparatus, digital display, special plate rolls and special support for the angle are optional equipment available to make your production easier.
